Auto

Basic Info.

Model NO.	FB5A
Motor Power	2.8kw
Working Table Size	L3750*W1980mm
Table Conveyer Belt Speed	10 - 14m/Min
Sewing Head Lifting Range	0 - 240mm
Air Pressure	0.6-0.8(MPa)
Sewing Head Speed	1642-2740r/Min
Transport Package	Wooden Case
Specification	Set
Trademark	Square
Origin	Nanjing China
HS Code	8452219000
Production Capacity	1000

Product Description

Model FB5A Auto flipping tape edge machine
Main application and Performance: Model FB5A Auto flipping tape edge machine is an ideal equipment for automatic product line of mattress production, by using the structure of moving and fixing sewing head. The tape edge machine could make the mattress move out, corner and flip automatically; its unique abilities such as sewing head quto raising or lowering at the corner, speed auto slowdown at the corner, sewing speed auto recovery after passing corner, adjustable sewing head tilting angle, adjustable sewing head lift, adjustable sewing quality.
Technical Feature:
1, heavy-duty 300U Chain stitch sewing head and variable speed control, the auto flipping tape edge machine is capable of taping all sizes of mattresses from crib to king.
2, Specifically designed for today's heavy mattresses, the tope sewing speed can run up to 3000 RPM.
3, The operator remains in a stationary sewing position while wide controlled conveyor belts move the mattress. The compression and turning devices built into the machine bring the mattress to the sewing head.
4, Sewing head could raise or lower and slowdown automatically at the corner, stitch more beautifully.
Technical data:

Sewing head type	Chain stitch
Sewing head lifting range	0 - 240mm
Tilting angle of Sewing head	25 - 65
Table conveyer belt speed	10 - 14m/min
Available mattress thickness	50 - 400mm
Sewing head speed	1642-2740r/min
Production efficiency	16-20 units/hour
Motor power	2.8KW
Air pressure	0.6-0.8(Mpa)
Working table size	L3750× W1980mm

You May also like:

http://sfcdjxc.en.made-in-china.com/ product/sbpmUreYJaWq/China-Mattress-Tape-Edge-Sewing-Machine-FB5-.html	http://sfcdjxc.en.made-in-china.com/ product/rhEnIUmMBQaX/ China-Mattress-Tape-Edge-Sewing-Machine-Fb4a-.html	http://sfcdjxc.en.made-in-china.com/ product/GoInjeBTYlVx/ China-Auto-Mattress-Tape-Edge-Sewing-Machine-FB-6-.html

Our Service:
1. After-sale service:
1) Installation & Commissioning: The seller can provide the installation, commissioning
and training service in buyer's factory, while the buyer needs to pay for VISA application,
air ticket, accommodation, and (if necessary) interpreting fee for seller's technician.
2) Warranty:For the machine above,the seller provides one year warranty starting from the
moment the seller dispatches the machines. For the detailed guarantee period of each
part, please refer to the operation manual.Wearing parts,consumption material and the
damage incurred by the buyer's incorrect operation are out of warranty range.
